Reference Standard：UL62,UL File No.:E345899
Conductor Material: Bare Copper,InsulationMaterial: TPE or PVC,Filler Material: PP Cord,Tape Material:Non-woven fabrics,Sheath Material: TPE or PVC
Rated temperature：-40℃～105℃
,Rated Voltage：300V；600V or 1000V,
Flame Test： VW-1 Test method Comply with UL 2556,
Min： Bending Radius: ≥5*OD,
Dielectric Voltage： 1.5kVac/1min. No Breakdown Test method Comply with UL 2556,Cold Bending：-40℃/4h No cracks Test method Comply with UL 2556,Hot Shock：150℃/1h No cracks Test method Comply with UL 2556,Oil Resistance：IRM902, 60℃/168h Tensile and Elongation ≥70% Unaged value,Crush Resistance：S≤12AWG 4.45kN, 12AWG＜S≤2AWG, 11.1kN, 2AWG＜S 15.6kN,Weather Resistance：720hin a xenon arc weatherometer, No cracks,Environmental Requirements：Compliant with RoHS 2.0 and REACH.
